Ci160RR-THX

  • Sale
  • Regular price €600
Tax included.


THX® Certified Ultra Architectural Speaker

Ci160RR-THX# is an ultra-high-performance loudspeaker featuring KEF's signature Uni-Q technology, designed for discreet in-ceiling or in-wall installation. As part of the Ci-R Series and a THX® Certified Ultra architectural loudspeaker, Ci160RR-THX is engineered to maintain exceptional sound quality at high outputs.

Available April


Customer Reviews

No reviews yet
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)

Ci160RR-THX

Ci160RR-THX’s Uni-Q® array boasts a 25mm high frequency tweeter mounted in the acoustic centre of a 165mm woofer, delivering the same, natural performance across the entire listening area. Plus, a Universal Cut-out system means its opening is the same as any 160mm KEF speaker for ease of installation and component selection.



#To meet THX Ultra distortion specifications, install with 3 litre rear enclosure and set the A/V processor speaker size to small

SPECIFICATIONS

The Details

Specifications

NOMINAL IMPEDANCE

4 Ohms



SENSITIVITY

90dB (2.83V/ 1m)



Frequency response (±6dB)
open-backed

52Hz - 24kHz



Frequency range (-10dB)

38Hz-30kHz



Nominal coverage (degrees)

130



OPTIONAL ROUGH IN FRAME

RIF160R



Optional rear enclosure

NA



Ideal Rear Volume(L)

20



Minimum Rear Volume(L)

10

RECOMMENDED AMPLIFIER POWER

10-190W



Recommended high-pass filter (Hz)

38Hz



PRODUCT EXTERNAL DIMENSION (H X W X D)

Diameter Ø: 234.6mm (9.24in.)
Depth :115mm (4.53in)



CUT-OUT DIMENSIONS (H x W)

Diameter Ø: 196mm (7.71in.)



Mounting Thickness (Maximum)

37mm (1.46in.)



Mounting Thickness (Minimum)

5mm (0.2in.)





MOUNTING DEPTH FROM SURFACE

110mm (4.33in.)



Max SPL (dB)

105



Crossover frequency

2.1kHz



Driver Unit

LF: 165mm (6.5in.) Uni-Q
HF: 25mm (1in.)

NET WEIGHT



REMARKS

KEF reserves the right, in line with continuing research and development, to amend or change specifications. E&OE. THX, the THX logo, and Ultra2 are trademarks of THX Ltd. THX and the THX logo are registered in the U.S. and other jurisdictions. All rights reserved.
